  • Caelon S — CAELON S7x 700-827 F WH STD 66

Caelon S / CAELON S7x 700-827 F WH STD 66

21013562 / 21019124

▼ Data Sheet

Caelon S adjustable surface mounted spotlights for the illumination of architectural facades, feature details, niches and structures. Class I electrical, IP66 with flood beam distribution. Remote driver to be ordered separately. Body: Die-cast aluminium in white. Stainless steel screws. ambient temperature: -20°C to +25°C. Complete with 2700K LED.

Dimensions: 75 x 75 x 75 mm
Luminaire input power: 11.1 W
Luminaire luminous flux: 940 lm
Luminaire efficacy: 85 lm/W
Weight: 0.63 kg

Mode selection
    • CE
    • IK06
    • IP66
    • SC1 - Protection Class 1

    ▼ Photometry

    Photometric configuration

    ▼ CalcExpress

    Use CalcExpress to quickly carry out quick online calculations of required indoor luminaire numbers for rectangular rooms. Enter the calculation parameters for your solution such as room dimensions, mounting height, height of the useful plane and required level of illuminance, and the site will instantly suggest a solution according to the light output ratio method.

    Step 1: Technical data
    (lm)
    (m)
    (m)
    (%)
    Step 2: Room Data
    (m)
    (m)
    (m)
    (m)
    (%)
    Step 3: Result
    (lx)
    (%)
