Prisma

  • Prisma
  • Prisma

Slim LED / fluorescent luminaire with curved prismatic diffuser for surface and suspended mounting

  • Surface and suspended installation, through wiring (TW) variants available
  • Robust and IP44 sealed housing extends applications to canteens, kitchens, laundry rooms, garages etc.
  • Curved opal (OP) / clear (CL) / frosted (FR) prismatic diffuser for more visual comfort (wide light distribution, reduced glare)
  • New highly efficient LED variants (up to 120 lm/W), sensor variants for even more energy saving
  • Available in two lengths (600 / 1200mm), easy replacement of T16 with LED thanks to the same dimensions

Materials and Finish

Body: Pre-painted white 0.7mm galvanised steel.
Endcaps: Shockproof ASA plastic, white.
Diffuser: Prismatic/opal acrylic (emergency versions in polycarbonate).

Installation and Mounting

Keyhole fixing positions Ø14mm for direct mounting to ceiling, wall or bracket mounting. Twin lamp versions balanced for suspended mounting using accessories. Fixing centres: 28W-1100mm and 35/49W-1400mm. Two cable entries Ø19mm in the centre of the body (not 14W version where cable entry is at end of body) and a knockout hole in the endcaps. Grommets included. Cable capacity 5 x 2.5mm².

New Product
LumExpress Product
eControl Product

Prisma

Prisma, through wired

DescriptionLuminaire power (W)Luminaire output (lm)   Catalogue No.TypeWt (kg)SAP Code
PRISMA LED3000-830 HF FR L600 TW272850E7273337LED1.5296630833
PRISMA LED3000-840 HF FR L600 TW273100E7273331LED1.5296630827
PRISMA LED4400-830 HF FR L1200 TW353900E7273338LED2.8196630834
PRISMA LED4400-840 HF FR L1200 TW354250E7273332LED2.8196630828
PRISMA LED6200-830 HF FR L1200 TW545700E7273339LED2.8196630835
PRISMA LED6200-840 HF FR L1200 TW546200E7273333LED2.8196630829

Prisma, dimmable

Prisma, dimmable, through wired

DescriptionLuminaire power (W)Luminaire output (lm)   Catalogue No.TypeWt (kg)SAP Code
PRISMA LED3000-830 HFIX FR L600 TW545700E7273349LED1.5296630845
PRISMA LED3000-840 HFIX FR L600 TW273100E7273343LED1.5296630839
PRISMA LED4400-830 HFIX FR L1200 TW353900E7273350LED2.8196630846
PRISMA LED4400-840 HFIX FR L1200 TW354250E7273344LED2.8196630840
PRISMA LED6200-830 HFIX FR L1200 TW545700E7273366LED2.8196630847
PRISMA LED6200-840 HFIX FR L1200 TW546200E7273345LED2.8196630841

Prisma, sensor versions

Description   Catalogue No.TypeWt (kg)SAP Code
PRISMA LED4400-830 HF FR MWS L1200E7273367LED2.7396630848
PRISMA LED4400-840 HF FR MWS L1200E7273368LED2.7396630849
