Urba Deco

  • Urba Deco
  • Urba Deco
  • Urba Deco

Smart, sophisticated architectural urban lighting

  • Unique architectural shape with a sophisticated light signature
  • A harmonious balance between performance and comfort
  • A choice of 25 light distributions and five mounting options offer versatility in lighting projects
  • Low weight and pre-wired for easy installation and tool-free maintenance

Materials and Finish

Canopy and base: die cast aluminium (AS9U3, LM24 equivalent, EN AC-46000) sandy black close to RAL 9005
Glass: 6mm thick clear or prismatic glass
Arms: die cast aluminium sandy black close to RAL 9005, covered with a white or black shield in plastic ASA

Installation and Mounting

Suitable for post top, catenary, suspension and wall mounting. Recommended mounting height: post top 3 to 6m, suspended 3 to 8m, catenary 5 to 8m. Post Top: mounting on spigot/columns Ø60mm or Ø76mm: with 2 screws (Allen 4). Maintenance with access from above. Pre-wired versions (6m), supplied complete and ready to install, in a single box. Catenary and suspension: fixing through 34G, maintenance with access from below. Dedicated columns and brackets available.

New Product
LumExpress Product
eControl Product

Urba Deco, MTP 500mA, Wide street, symmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 WS-S CL CL2 6M MTP60-T384281LED7.5096272903
UD 24L50-740 WS-S CL CL2 6M MTP60-T384281LED7.5096273117

Urba Deco, MTP 500mA, Wide street, asymmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 WS-A CL CL2 6M MTP60-T384281LED7.5096272907
UD 24L50-740 WS-A CL CL2 6M MTP60-T384281LED7.5096273121

Urba Deco, MTP 250mA CL, Wide street comfort, symmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L25-730 WSC-S CL CL2 6M MTP60-L202102LED7.5096272910
UD 24L25-730 WSC-S CL CL2 6M MTP60-T202102LED7.5096272909
UD 24L25-740 WSC-S CL CL2 6M MTP60-L202313LED7.5096273124
UD 24L25-740 WSC-S CL CL2 6M MTP60-T202313LED7.5096273123

Urba Deco, MTP 250mA PR, Wide street comfort, symmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L25-730 WSC-S PR CL2 6M MTP60-L201583LED7.5096273961
UD 24L25-730 WSC-S PR CL2 6M MTP60-T201583LED7.5096272931
UD 24L25-740 WSC-S PR CL2 6M MTP60-L201741LED7.5096273963
UD 24L25-740 WSC-S PR CL2 6M MTP60-T201741LED7.5096273145

Urba Deco, MTP 350mA PR, Wide street comfort, symmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 48L35-730 WSC-S PR CL2 6M MTP60-T514264LED7.5096272934
UD 48L35-740 WSC-S PR CL2 6M MTP60-T514692LED7.5096273148

Urba Deco, MTP 500mA CL, Wide street comfort, symmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 WSC-S CL CL2 6M MTP60-L383843LED7.5096272914
UD 24L50-730 WSC-S CL CL2 6M MTP60-T383843LED7.5096272913
UD 24L50-740 WSC-S CL CL2 6M MTP60-L384229LED7.5096273128
UD 24L50-740 WSC-S CL CL2 6M MTP60-T384229LED7.5096273127

Urba Deco, MTP 500mA PR, Wide street comfort, symmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 WSC-S PR CL2 6M MTP60-L382894LED7.5096273977
UD 24L50-730 WSC-S PR CL2 6M MTP60-T382894LED7.5096272933
UD 24L50-740 WSC-S PR CL2 6M MTP60-L383185LED7.5096273979
UD 24L50-740 WSC-S PR CL2 6M MTP60-T383185LED7.5096273147

Urba Deco, MTP 250mA CL, Wide street comfort, asymmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L25-730 WSC-A CL CL2 6M MTP60-L202102LED7.5096272916
UD 24L25-730 WSC-A CL CL2 6M MTP60-T202102LED7.5096272915
UD 24L25-740 WSC-A CL CL2 6M MTP60-L202313LED7.5096273130
UD 24L25-740 WSC-A CL CL2 6M MTP60-T202313LED7.5096273129

Urba Deco, MTP 250mA PR, Wide street comfort, asymmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L25-730 WSC-A PR CL2 6M MTP60-L201583LED7.5096273969
UD 24L25-730 WSC-A PR CL2 6M MTP60-T201583LED7.5096272935
UD 24L25-740 WSC-A PR CL2 6M MTP60-L201741LED7.5096273971
UD 24L25-740 WSC-A PR CL2 6M MTP60-T201741LED7.5096273149

Urba Deco, MTP 350mA PR, Wide street comfort, asymmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 48L35-730 WSC-A PR CL2 6M MTP60-T514264LED7.5096272938
UD 48L35-740 WSC-A PR CL2 6M MTP60-T514692LED7.5096273152

Urba Deco, MTP 500mA CL, Wide street comfort, asymmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 WSC-A CL CL2 6M MTP60-L383843LED7.5096272920
UD 24L50-730 WSC-A CL CL2 6M MTP60-T383843LED7.5096272919
UD 24L50-740 WSC-A CL CL2 6M MTP60-L384229LED7.5096273134
UD 24L50-740 WSC-A CL CL2 6M MTP60-T384229LED7.5096273133

Urba Deco, MTP 500mA PR, Wide street comfort, asymmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 WSC-A PR CL2 6M MTP60-L382894LED7.5096273985
UD 24L50-730 WSC-A PR CL2 6M MTP60-T382894LED7.5096272937
UD 24L50-740 WSC-A PR CL2 6M MTP60-L383185LED7.5096273987
UD 24L50-740 WSC-A PR CL2 6M MTP60-T383185LED7.5096273151

Urba Deco, MTP 500mA, Extra wide street comfort, symmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 48L50-730 EWSC-S CL CL2 6M MTP60-T727713LED7.5096272921
UD 48L50-740 EWSC-S CL CL2 6M MTP60-T728487LED7.5096273135

Urba Deco, MTP 500mA, Extra wide street comfort, asymmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 48L50-730 EWSC-A CL CL2 6M MTP60-T727713LED7.5096272922
UD 48L50-740 EWSC-A CL CL2 6M MTP60-T728487LED7.5096273136

Urba Deco, MTP 500mA, Extra wide road, symmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 EWR-S CL CL2 6M MTP60-T383986LED7.5096272923
UD 24L50-740 EWR-S CL CL2 6M MTP60-T384386LED7.5096273137

Urba Deco, MTP 500mA, Extra wide road, asymmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 EWR-A CL CL2 6M MTP60-T383986LED7.5096272924
UD 24L50-740 EWR-A CL CL2 6M MTP60-T384386LED7.5096273138

Urba Deco, MTP 350mA, Street comfort, symmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 48L35-730 SC-S CL CL2 6M MTP60-T515871LED7.5096272929
UD 48L35-740 SC-S CL CL2 6M MTP60-T516460LED7.5096273143

Urba Deco, MTP 500mA, Street comfort, symmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 SC-S CL CL2 6M MTP60-T383986LED7.5096272927
UD 24L50-740 SC-S CL CL2 6M MTP60-T384386LED7.5096273141

Urba Deco, MTP 350mA, Street comfort, asymmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 48L35-730 SC-A CL CL2 6M MTP60-T515871LED7.5096272930
UD 48L35-740 SC-A CL CL2 6M MTP60-T516460LED7.5096273144

Urba Deco, MTP 500mA, Street comfort, asymmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 SC-A CL CL2 6M MTP60-T383986LED7.5096272928
UD 24L50-740 SC-A CL CL2 6M MTP60-T384386LED7.5096273142

Urba Deco, MSU 500mA, Wide street, asymmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 WS-A CL CL2 MSU-T384128LED6.7096272966
UD 24L50-740 WS-A CL CL2 MSU-T384542LED6.7096273184

Urba Deco, MSU 250mA CL, Wide street comfort, asymmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L25-730 WSC-A CL CL2 MSU-T202257LED6.7096272969
UD 24L25-740 WSC-A CL CL2 MSU-T202484LED6.7096273187

Urba Deco, MSU 250mA PR, Wide street comfort, asymmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L25-730 WSC-A PR CL2 MSU-T201686LED6.7096272984
UD 24L25-740 WSC-A PR CL2 MSU-T201856LED6.7096273202

Urba Deco, MSU 350mA PR, Wide street comfort, asymmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 48L35-730 WSC-A PR CL2 MSU-T514543LED6.7096272986
UD 48L35-740 WSC-A PR CL2 MSU-T514999LED6.7096273204

Urba Deco, MSU 500mA PR, Wide street comfort, asymmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 WSC-A PR CL2 MSU-T383084LED6.7096272985
UD 24L50-740 WSC-A PR CL2 MSU-T383393LED6.7096273203

Urba Deco, MSU 500mA, Extra wide street comfort, asymmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 48L50-730 EWSC-A CL CL2 MSU-T728189LED6.7096272974
UD 48L50-740 EWSC-A CL CL2 MSU-T729011LED6.7096273192

Urba Deco, MSU 500mA, Extra wide road, asymmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 EWR-A CL CL2 MSU-T384223LED6.7096272976
UD 24L50-740 EWR-A CL CL2 MSU-T384647LED6.7096273194

Urba Deco, MSU 500mA, Street comfort, asymmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 SC-A CL CL2 MSU-T384270LED6.7096272980
UD 24L50-740 SC-A CL CL2 MSU-T384669LED6.7096273198

Urba Deco, MSU 500mA, Narrow road, asymmetric optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 48L50-740 NR-A CL CL2 1M IN MSU-T729221LED7.0096273992

Urba Deco, MCA 500mA, Wet road, symmetrical optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
UD 24L50-730 RWET-S CL CL2 MCA-T384123LED7.0096272989
