R2L2

  • R2L2
  • R2L2

A complete road lantern family at the forefront of LED technology to offer excellent lighting performance and cover all applications

  • Comprehensive range available in three sizes with extensive optical, lumen and light distribution choice for all road applications
  • Efficient (up to 153lm/W) R-PEC optic offering 15 types of light distribution for precise light placement with no waste light
  • Maximises energy savings with a wide range of intelligent lighting control solutions from stand alone dimming to fully remote control via central monitoring system
  • Attractive, universal and integrated spigot offering flexibility through top and side entry as well as tilt adjustment

Materials and Finish

Housing, canopies, spigot: die-cast aluminium with light grey 150 sanded textured (close to RAL9006)
Glass: 4mm thick (XS: 5mm thick)
Screws: stainless steel

Powder coating texturised light grey as standard. Other RAL or AKZO colours available on request. Other special treatment on request.

Installation and Mounting

Post-top mounting: Ø60-76mm
Side-entry mounting: Ø48-60mm or Ø32-42-48-60mm (CL1 as standard)
Operating temperature: -25°C < Ta < +35°C
Suitable for use up to +50°C through the use of heat regulation system
Recommended mounting height: 4m to 14m
Adjustable tilt angle side: 0°/ -5°/ -10°/ -15°
Adjustable tilt angle top 0°/ +5°/ +10°

New Product
LumExpress Product
eControl Product

R2L2 Extra small, Narrow road optic

R2L2 Small, Narrow road optic

DescriptionLuminaire power (W)Luminaire output (lm)   Catalogue No.TypeWt (kg)SAP Code
R2L2 S 12L35-740 NR BPS CL2 GY152049LED8.8996275551
R2L2 S 24L50 NR L740 CL2385632E7728046LED9.3596266021
R2L2 S 36L70 NR L740 CL27811250E7728021LED9.3296266202
R2L2 S 36L70-740 NR BPS CL2 GY7811250LED9.7096275559

R2L2 Small, Narrow road optic, configured products

DescriptionLuminaire power (W)Luminaire output (lm)   Catalogue No.TypeWt (kg)SAP Code
R2L2 S 24L50 NR 730 CL2 BP385135LED9.3596266020
R2L2 S 24L50 NR L740 CL2 BP385632E7728045LED9.3596266022
R2L2 S 24L70 NR L740 CL2 BP537561E7728035LED9.3596266073
R2L2 S 36L70 NR L740 CL2 BP7811250E7728020LED9.3296266203
R2L2 S 48L70 NR L740 CL2 BP10114898E7728005LED9.7896266350

R2L2 Small, Wide street optic

DescriptionLuminaire power (W)Luminaire output (lm)   Catalogue No.TypeWt (kg)SAP Code
R2L2 S 12L35 WS L740 CL2 BPS152036E7728056LED8.8996265889
R2L2 S 12L50 WS L740 CL2 BPS202807E7728054LED8.8996265917
R2L2 S 12L70 WS L740 CL2 BPS283778E7728050LED8.8996265946
R2L2 S 24L50 WS L740 CL2385594E7728039LED9.3596266042
R2L2 S 24L70 WS L740 CL2537510E7728032LED9.3596266080
R2L2 S 36L50 WS L740 CL2558357E7728026LED9.3296266172
R2L2 S 36L70 WS L740 CL27811175E7728018LED9.3296266210
R2L2 S 48L50 WS L740 CL27211095E7728009LED9.3796266322
R2L2 S 48L70 WS L740 CL210114799E7728003LED9.7896266367

R2L2 Small, Wide street comfort optic

DescriptionLuminaire power (W)Luminaire output (lm)   Catalogue No.TypeWt (kg)SAP Code
R2L2 S 36L70 WSC L740 CL27811013E7728016LED9.3296266216
R2L2 S 48L70 WSC L740 CL210114584E7728001LED9.7896266375

R2L2 Small, Wet road optic

DescriptionLuminaire power (W)Luminaire output (lm)   Catalogue No.TypeWt (kg)SAP Code
R2L2 S 24L50 RWT L740 CL2385700E7728043LED9.3596266030
R2L2 S 48L50 RWT L740 CL27211306E7728012LED9.3796266306

R2L2 Small, Road comfort optic

DescriptionLuminaire power (W)Luminaire output (lm)   Catalogue No.TypeWt (kg)SAP Code
R2L2 S 12L70 RC 740 CL2283846E7728052LED8.8996268421
R2L2 S 24L35 RC 740 CL2284134E7728049LED9.3596268432
R2L2 S 24L50 RC L740 CL2385694E7728044LED9.3596266025
R2L2 S 24L70 RC 740 CL2537645E7728034LED9.3596268455
R2L2 S 36L35 RC 740 CL2406184E7728029LED9.3296268466
R2L2 S 36L70 RC 740 CL27811375LED9.3296268489
R2L2 S 48L70 RC 740 CL210115064LED9.7896268516

R2L2 Small, Wide road optic

DescriptionLuminaire power (W)Luminaire output (lm)   Catalogue No.TypeWt (kg)SAP Code
R2L2 S 12L70 WR 740 CL2283808E7728051LED8.8996268424
R2L2 S 24L50 WR L740 CL2385638E7728041LED9.3596266034
R2L2 S 24L70 WR 740 CL2537569E7728033LED9.3596268458
R2L2 S 36L70 WR 740 CL27811263E7728019LED9.3296268492

R2L2 Small, Extra wide street optic

DescriptionLuminaire power (W)Luminaire output (lm)   Catalogue No.TypeWt (kg)SAP Code
R2L2 S 24L50 EWS L740 CL2385525E7728048LED9.3596266005
R2L2 S 24L70 EWS L740 CL2537418E7728037LED9.3596266056
R2L2 S 36L50 EWS L740 CL2558254E7728028LED9.3296266145
R2L2 S 36L70 EWS L740 CL27811038E7728024LED9.3296266186
R2L2 S 48L50 EWS L740 CL27210959E7728014LED9.3796266276
R2L2 S 48L70 EWS L740 CL2 BP10114617E7728007LED9.7896266335

R2L2 Small, Pedestrian crossing optic

DescriptionLuminaire power (W)Luminaire output (lm)   Catalogue No.TypeWt (kg)SAP Code
R2L2 S 36L70 IVS 740 CL27810888E7728022LED9.3296268486
R2L2 S 48L70 IVS 740 CL210114418E7728006LED9.7896268515

R2L2 Medium, Narrow road optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
R2L2 M 60L70 NR L740 CL212618750LED13.0796266446
R2L2 M 60L70-740 NR BPS CL2 GY12618750LED14.7596275565
R2L2 M 72L50 NR L740 CL210716766LED13.0596266502
R2L2 M 72L50-740 NR BPS CL2 GY10716766LED0.0096275567
R2L2 M 72L70-740 NR BPS CL2 GY15022374LED13.3496275568
R2L2 M 72L70V2 NR L740 CL215022374LED13.3496266538

R2L2 Medium, Wide street comfort optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
R2L2 M 60L50 WSC L740 CL28913721LED13.0796266438
R2L2 M 60L70 WSC L740 CL212618354LED13.0796266472
R2L2 M 84L50 WSC 740 CL212319081LED13.1096266641
R2L2 M 84L70 WSC 740 CL217625395LED13.3996266677
R2L2 M 96L50V2 WSC 740 CL214121841LED13.4596266746

R2L2 Medium, Wet road optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
R2L2 M 84L50 RWT 740 CL212319731LED13.1096266619

R2L2 Medium, Road comfort optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
R2L2 M 60L70 RC L740 CL212618959LED13.0796266451
R2L2 M 72L50 RC L740 CL210716952LED13.0596266507
R2L2 M 72L70V2 RC L740 CL215022622LED13.3496266544
R2L2 M 96L70 RC 740 CL220130054LED14.2696266764
R2L2 M 96L90 RC 740 CL226236748LED14.3096274647

R2L2 Medium, Road comfort optic, configured products

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
R2L2 M 84L70 RC 740 CL217626231LED13.3996266656

R2L2 Medium, Wide road optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
R2L2 M 60L70 WR L740 CL212618771LED13.0796266456

R2L2 Medium, Pedestrian crossing optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
R2L2 M 60L70 IVS 740 CL212618146LED13.0796268314
R2L2 M 72L70V2 IVS 740 CL215021653LED13.3496268343

R2L2 Medium, Street comfort optic

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
R2L2 M 96L90 SC 740 CL226236627LED14.3096274649

R2L2 Medium, Extra wide road optic, configured products

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
R2L2 M 96L90 EWR 740 CL226235214LED14.3096274642

R2L2 Attachments

Description   Wt (kg)SAP Code
R2L2 M PAIR OF LOUVRES0.4496268851
R2L2 S PAIR OF LOUVRES0.4596268850
RX IK100.1096631361
RX Louvre front / back / side0.1096631362
